Wells and mounting brackets for thermostats
Regin

Wells and mounting brackets for thermostats

Specifications

Articles

(10 st)
  • DR-01 - Regin
    DR-01
    Brass pocket 120mm, Ø external 11 mm, Ø internal 10 mm, connection R 1/2”
    Tube length
    120 mm
    Total well length
    140 mm
    External tube diameter
    11 mm
    Internal tube diameter
    10 mm
    Connection
    R 1/2"
    Well material
    Brass / Cu-Ni
    Fixing stopper for capillary
    Yes
  • DR-02 - Regin
    DR-02
    Stainless steel pocket AISI 304, 120 mm, Ø external 12 mm, Ø internal 10 mm, connection R 1/2”
    Tube length
    120 mm
    Total well length
    148 mm
    External tube diameter
    12 mm
    Internal tube diameter
    10 mm
    Connection
    R 1/2"
    Well material
    Stainless steel (AISI 304)
    Fixing stopper for capillary
    Yes
  • DR-05 - Regin
    DR-05
    Set of mounting brackets for capillary fixing
    Fixing stopper for capillary
    Set of 6 mounting plastic brackets
  • DR-16 - Regin
    DR-16
    Brass pocket 120mm, Ø external 10 mm, Ø internal 8,5 mm, connection R 1/2”
    Tube length
    120 mm
    Total well length
    140 mm
    External tube diameter
    10 mm
    Internal tube diameter
    8.5 mm
    Connection
    R 1/2"
    Well material
    Brass / Cu-Ni
    Fixing stopper for capillary
    Yes
  • DR-17 - Regin
    DR-17
    Stainless steel pocket AISI 304, 120 mm, Ø external 10mm, Ø internal 8,5 mm, connection R 1/2”
    Tube length
    120 mm
    Total well length
    148 mm
    External tube diameter
    10 mm
    Internal tube diameter
    8.5 mm
    Connection
    R 1/2"
    Well material
    Stainless steel (AISI 304)
    Fixing stopper for capillary
    Yes
  • DR-16/14 - Regin
    DR-16/14
    Brass immersion well, 120 mm. Suitable for MTIB60, MTIB90 and MTIB120.
    Tube length
    120 mm
    Total well length
    140 mm
    External tube diameter
    10 mm
    Internal tube diameter
    8.5 mm
    Connection
    R 1/2"
    Well material
    Brass / Cu-Ni
    Fixing stopper for capillary
    No
  • DR-17/14 - Regin
    DR-17/14
    Stainless steel EN 1.4301 immersion well, 120 mm. Suitable for MTIB60, MTIB90 and MTIB120.
    Tube length
    120 mm
    Total well length
    148 mm
    External tube diameter
    10 mm
    Internal tube diameter
    8.5 mm
    Connection
    R 1/2"
    Well material
    Stainless steel (AISI 304)
    Fixing stopper for capillary
    No
  • DR-25 - Regin
    DR-25
    Spiral protection bracket for capillary
    Fixing stopper for capillary
    Spiral protection bracket
  • DR-31/14 - Regin
    DR-31/14
    Stainless steel pocket AISI 304, 120 mm, ø external 9 mm, ø internal 7 mm, connection R 1/2"
    Tube length
    120 mm
    Total well length
    148 mm
    External tube diameter
    9 mm
    Internal tube diameter
    7 mm
    Connection
    R 1/2"
    Well material
    Stainless steel EN 1.4301
    Fixing stopper for capillary
    Yes
  • DR-40/14 - Regin
    DR-40/14
    Brass pocket 108 mm, Ø external 16 mm, Ø internal 15 mm, connection R 1/2”
    Tube length
    108 mm
    Total well length
    128 mm
    External tube diameter
    16 mm
    Internal tube diameter
    15 mm
    Connection
    R 1/2"
    Well material
    Brass / Cu-Ni
    Fixing stopper for capillary
    Yes

Specifications

Specifications for Wells and mounting brackets for thermostats
