TG-AH4/NTC10-01 Clamp-on sensor with housing
Clamp-on sensor with housing
Navigate on this page
Specifications
| Mounting | Clamp-on |
|---|---|
| Dimensions, external (WxHxD) | 104x78x51 mm |
| Media temp limits | -20…120 °C |
| Time constant | 3 s |
| Element type | NTC10-01 |
| Measuring range, temp | -20…120 °C |
| Nominal resistance | 10 kΩ (25°C) |
| Protection class | IP42 |
|---|---|
| Weight, incl. packaging | 0.15 kg |
| Cable gland | M16x1,5 |
| Terminal type | Screw Terminal |
| Detachable terminal | Yes |
| Terminal wire size | 1.5 mm² |
| Material, housing | Polycarbonate (PC) |
Software & documentation
Product sheet
Instructions
Other documentation
Accessories
PASTA-20
Heat-conductive paste in tube, 20 g
